Victor VC88E User Manual

2-7. Capacitance C
Range Accuracy Resolution
1pF
40nF ±(2.5%+6d)
10pF
400nF 100pF
4µF 1nF
40µF
±(3.5%+8d)
10nF
400µF ±(5.0%+8d) 100nF
2-8. Frequency F
Range Accuracy Resolution
100Hz 0.1Hz
1000Hz 1Hz
10kHz 10Hz
100kHz 100Hz
1MHz 1kHz
30MHz
±(0.5%+4d)
10kHz
Input sensitivity:1.0V.
2-9. Diode and continuity performance test
Range Value displayed Testing condition
Forward voltage drop of diode
Forward DCA is approx. 0.5mA, the backward
voltage is approx 1.5V
Buzzer makes a long sound while resistance
is less than (30±20)Ω
Open circuit voltage is approx. 0.5V
CAUTION: DO NOT INPUT VOLTAGE IN THIS RANGE!
2-10. Temperature
Range Accuracy Resolution
-40°C-1000°C
-0°C ±(1.0%+4)
0°C - 400°C ±(1.0%+4)
+
400C ±(1.5%+15)
1°C
0°F-1832°F
-750°F ±(0.8%+5)
+750°F ±(1.5%+15)
1°F
Sensor: TP01(K type thermocouple)
CAUTION: DO NOT INPUT VOLTAGE IN THIS RANGE!

Victor VC88E Specifications

General

Brand	Victor
Model	VC88E
Category	Multimeter
Language	English
