Position the tip at the point shown in the
figure during delivery, considering that the
hot water and cold water valves are parallel,
simply verify the operation of this relay to
check both valves.
7.7.1 REMOVAL OF
THE HOT WATER VALVE
To remove the hot water valve, it is nec-
essary to extract both hot and cold water
valves. Proceed as it follows:
1
Empty the steam boiler by following the
procedure described in paragraph 5.2.
NOTE
It is not possible to operate with pressure
in the steam boiler.
2
Remove the cup holder surface and the
left side panel as described in Chapter 3.
3
Utilizing a 13 mm wrench, remove the inlet
pipe of hot water.
