Unscrew and remove the pressure trans-
ducer by hand.
8.5.2 REMOVAL OF THE STEAM
BOILER PRESSURE TRANSDUCER
The steam boiler pressure transducer is
placed on the front of the machine, over the
pressure gauge.
To remove it, proceed as it follows:
1
Remove the cup holder surface, the side
panels, the drip tray and the lower front
panel, as described in chapter 3.
2
Unplug the connector.
3
Unscrew and remove the pressure trans-
ducer by hand.
35
35
37
37
36
36
38
38
08
