2.8 ADJUSTMENT OF
THE PRESSURE
The pressure of the machine must be set
while the coffee is brewing. While coffee is
delivered, check with the smartphone app
Victoria Arduino E1 that the value reaches
9 bar, the optimum value.
In the event that it would be necessary, use
the knob located below the machine to
make an appropriate adjustment.
Turning the knob clockwise raises the pres-
sure, turning it counter-clockwise decreas-
es the pressure.
NOTE
By factory the pump pressure is set to
reach 9 bar.
2.7 WATER INPUT PRESSURE
FOR DIRECT CONNECTION
VERSION
Check with the smartphone app Victoria
Arduino E1 that the water input pressure is
between 0 and 5 bar.
NOTE
If the pressure is more than 5 bar, insert
a pressure reducer upstream to ensure
a value between 0 and 5 bar.
21
21
22
22
02

Victoria Arduino EAGLE ONE PRIMA Specifications

General

Model	EAGLE ONE PRIMA
Category	Coffee Maker
Brand	Victoria Arduino
Type	Espresso Machine
Boiler Material	Stainless Steel
Voltage	220-240 V
Frequency	50/60 Hz
Steam Wand	Yes
Hot Water Tap	Yes
Group Heads	1
Material	Stainless Steel
Water Supply	Tank
Color Options	Black, White, Red
