Victoria Arduino EAGLE ONE PRIMA Service Manual

181
1
1
1
1
1
1
1
1
1
1
1
1
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
D
D
DI
A
A
A
G
G
G
R
R
RA
A
A
M
M
MS
S
S
POSITION DESCRIPTION
1
1
Water tank
2
Water tank electrovalve
3
Pump 10 bar - 70 l/h - 170 W
4
Water mains inlet
5
Check valve
6
Water mains inlet electrovalve
7
Flowmeter
8
Calibrated orifice
9
Coffee boiler 0.14 l - 600 W
10
Pouring group electrovalve
11
Filter holder outlet
12
Discharge outlet
13
Safety valve 16,5 bar
14
Anti-vacuum valve
15
Safety valve 3 bar
16
Steam boiler 1,5 l - 1600 W
17
Water level electrovalve
18
Steam electrovalve
19
Water inlet electrovalve
20
Steam wand outlet
21
Hot water outlet
13

Victoria Arduino EAGLE ONE PRIMA Specifications

General

Model	EAGLE ONE PRIMA
Category	Coffee Maker
Brand	Victoria Arduino
Type	Espresso Machine
Boiler Material	Stainless Steel
Voltage	220-240 V
Frequency	50/60 Hz
Steam Wand	Yes
Hot Water Tap	Yes
Group Heads	1
Material	Stainless Steel
Water Supply	Tank
Color Options	Black, White, Red
