Victoria Arduino EAGLE ONE PRIMA Service Manual

185
1
1
1
1
1
1
1
1
1
1
1
1
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
D
D
DI
A
A
A
G
G
G
R
R
RA
A
A
M
M
MS
S
S
POSITION DESCRIPTION
1
1
Steam boiler heating element (1600 W)
2
Steam boiler temperature probe
3
Compressor
4
LED strip
5
Left LED spotlight
6
Right LED spotlight
7
Volumetric counter
8
Filter holder presence sensor
9
Water tank presence sensor
10
Control unit
11
Keyboard flat
12
Hot water pressure transducer
13
Steam boiler pressure transducer
14
Pouring group temperature probe
15
Easycream temperature probe
16
Pouring group heating element (300 W)
17
Coffee boiler heating element (600 W)
18
Coffee boiler temperature probe
19
AC/DC Transformer
20
Relay
21
Relay switch
22
Power relay
23
Master switch
24
Pump motor
25
Tank solenoid valve
26
Water stop solenoid valve
27
Air solenoid valve
28
Steam solenoid valve
29
Level solenoid valve
30
Steam / Hot water solenoid valve
31
Steam / Hot water solenoid valve
32
Pouring group solenoid valve
33
Temperature switch
34
110 V single phase power IN
35
Steam knob connector (CN2)
36
Hot water knob connector (CN3)
37
Keyboard and ghost display
38
Pressure switch
39
Thermo-fuse
40
Remote control module
13

Victoria Arduino EAGLE ONE PRIMA Specifications

General

Model	EAGLE ONE PRIMA
Category	Coffee Maker
Brand	Victoria Arduino
Type	Espresso Machine
Boiler Material	Stainless Steel
Voltage	220-240 V
Frequency	50/60 Hz
Steam Wand	Yes
Hot Water Tap	Yes
Group Heads	1
Material	Stainless Steel
Water Supply	Tank
Color Options	Black, White, Red
