Victoria Arduino EAGLE ONE PRIMA Service Manual

189
1
1
1
1
1
1
1
1
1
1
1
1
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
S
S
P
P
P
A
A
AR
R
R
E
E
E
P
P
PA
A
A
R
R
R
T
T
S
S
CODE DESCRIPTION END VALIDITY
0
00000073
S/S WASHER D.8x4x1 UNI6592
00000118
S/S HEX SOCKET CAP SCREW M4x12 5931
00000144
GALVANIC FLANGED NUT M5 UNI 6923
00000160
S/S WASHER D4X12 UNI 6593
00000175
S/S CROSS HEAD CAP SCREW M4X10
00300041
S/S FH GRUB SCREW M5x10
03003218
RIGHT SUPPORT COVER GROUP VA388
03003219
LEFT SUPPORT COVER GROUP VA388
03003861
REAR INFERIOR PROFILE EAGLE ONE 1GR ALUMINIUM
03003861.BV
REAR INFERIOR PROFILE WHITE
03003861.NOV
REAR INFERIOR PROFILE MATT BLACK
03003871
FRONTAL PANEL 1GR EAGLE ONE CHROMED ALUMINIUM
03003890
FRONT SIDE LOGO EAGLE ONE PRIMA
03003911
INFERIOR FRONT PLATE 1GR EAGLE ONE
03003915
DRIP TRAY 1GR
03003921
MESH WORKTOP 1GR EAGLE ONE
03003931
SUP BACK PANEL SUPPORT 1GR
03003982
TANK COVER 1GR.
03003984
SUPERIOR CUP HOLDER 1GR.
04001161
LED STRIP 1GR EAGLE ONE
06100314
RIGHT TERMINAL INFERIOR BACKSIDE PROFILE
06100316
LEFT TERMINAL INFERIOR BACKSIDE PROFILE
06100320
REAR EAGLE LOGO STEELUX
08000114
SPRING REAR LED FIXING
09100012
GAUGE SCALE 0-4 BAR 1/8 D.40 VA
980100000029960001
RIGHT SIDE PANEL 1GR. STEELUX
980100000029960002
RIGHT SIDE PANEL 1GR. MATT BLACK
980100000029960003
RIGHT SIDE PANEL 1GR. WHITE
980100000029960004
RIGHT SIDE PANEL 1GR. RED CAPPELLINI
980100000029960005
RIGHT SIDE PANEL 1GR. GREEN CAPPELLINI
980100000029960006
RIGHT SIDE PANEL 1GR. BLUE CAPPELLINI
980100000029980001
LEFT SIDE PANEL 1GR. STEELUX
980100000029980002
LEFT SIDE PANEL 1GR. MATT BLACK
980100000029980003
LEFT SIDE PANEL 1GR. WHITE
980100000029980004
LEFT SIDE PANEL 1GR. RED CAPPELLINI
980100000029980005
LEFT SIDE PANEL 1GR. GREEN CAPPELLINI
980100000029980006
LEFT SIDE PANEL 1GR. BLUE CAPPELLINI
980100000030110001
REAR PANEL ASS. 1 GR. STEELUX WITH LIGHTS
980100000030110002
REAR PANEL ASS. 1 GR. MATT BLACK WITH LIGHTS
980100000030110003
REAR PANEL ASS. 1 GR. WHITE WITH LIGHTS
980100000030110004
REAR PANEL ASS. 1 GR. CAPPELLINI RED WITH LIGHTS
980100000030110005
REAR PANEL ASS. 1 GR. CAPPELLINI GREEN WITH LIGHT
980100000030110006
REAR PANEL ASS. 1 GR. CAPPELLINI BLUE WITH LIGHTS
980100000030310001
INFERIOR RETRO FRAME SET 1GR STEELUX
980100000030310002
INFERIOR RETRO FRAME SET 1GR MATT BLACK
980100000030460000
BACKSIDE FRAME EAGLE ONE 1GR WOOD
980100000030560000
RIGHT SIDE PANEL EAGLE ONE SPECIAL COLOUR
980100000030570000
LEFT SIDE PANEL EAGLE ONE SPECIAL COLOUR
980100000030610000
REAR INFERIOR PROFILE 1GR SPECIAL COLOUR
980100000030660000
BACKSIDE FRAME 1GR SPECIAL COLOUR
980100000030810000
REAR EAGLE LOGO EAGLE ONE SPECIAL COLOUR
14

Victoria Arduino EAGLE ONE PRIMA Specifications

General

Model	EAGLE ONE PRIMA
Category	Coffee Maker
Brand	Victoria Arduino
Type	Espresso Machine
Boiler Material	Stainless Steel
Voltage	220-240 V
Frequency	50/60 Hz
Steam Wand	Yes
Hot Water Tap	Yes
Group Heads	1
Material	Stainless Steel
Water Supply	Tank
Color Options	Black, White, Red
