Victoria Arduino EAGLE ONE PRIMA Service Manual

199
1
1
1
1
1
1
1
1
1
1
1
1
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
S
S
P
P
P
A
A
AR
R
R
E
E
E
P
P
PA
A
A
R
R
R
T
T
S
S
CODE DESCRIPTION END VALIDITY
0
00000104
S/S CROSS HEAD COUNTERSUNK SCREW M4x10 DIN965
01000108
TAP MRF 1/8 FF 604
02280036
O RING STEAM WAND NOZZ. D6x1.2 EPDM70
02280047
GASKET OR 17,86x2,62 NBR
02600006
TEFLON GASKET FOR STEAM LANCE BALL
03003980
EASY CREAM COMPONENT SUPPORT
04100042
2WAY SOLENOID 1/8-1/8 220-230V50/60Hz F2 CE
04100043
2WAY SOLENOID 1/8-1/8 110-120V 60Hz F2 UL TH1xM4
04901531
PT1000 PROBE FOR STEAM WAND
05000015
TUBE FASTENING WES 6R 1/8
07300714
L FITTING 1/8 M - FITTINGS.6
07300870
FITTING 3/8 STEAM-WATER ARTICULATED WAND
07300872
COMPASS JOINT STEAM-WATER WAND
08000112
SPRING FOR ARTICULATED WAND
11600001.W
WHITE SILICONE PIPE 4x7,5 60Sh(1mt=41gr)
11740003
CALIBRATED TEFLON PIPE 6/4
75006038.1
STEAM NOZZLE M8,65X0,75 F1,2 ESAG.1,2
98060000000513
ASSEMBLY JOINT + EASY WAND WITH PROBE
98170000000033
MICROCOMPRESSOR + SUPPORT SET TALENTO
14

Victoria Arduino EAGLE ONE PRIMA Specifications

General

Model	EAGLE ONE PRIMA
Category	Coffee Maker
Brand	Victoria Arduino
Type	Espresso Machine
Boiler Material	Stainless Steel
Voltage	220-240 V
Frequency	50/60 Hz
Steam Wand	Yes
Hot Water Tap	Yes
Group Heads	1
Material	Stainless Steel
Water Supply	Tank
Color Options	Black, White, Red
