Victoria Arduino EAGLE ONE PRIMA Service Manual

201
1
1
1
1
1
1
1
1
1
1
1
1
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
S
S
P
P
P
A
A
AR
R
R
E
E
E
P
P
PA
A
A
R
R
R
T
T
S
S
CODE DESCRIPTION END VALIDITY
0
00000060
GALVANIC MEDIUM NUT AQ M3
00000192
S/S SCREW M4x8 TE UNI 5739
01000636
COFFEE BOILER INSULATION EAGLE ONE
02280032
GASKET O RING 114 D15 EP 851
02280045
GASKET O RING 29,82x2,62 EPDM
03000004.1
DOUBLE BRACKET FOR THERMOSTAT
03003964
SUPPORT DOSER BRACKET
04000198
FOIL HOLDER M 6.3 D 4.2 45°
04900027
BRASS FLOWMETER 1/4-1/4GAS -ATT. HEAD 2,8x0,5
04900775.1
TEMPERATURE PROBE 150° NTC ATT.1/8 SS 4X20
07300001
L FITTING 1/8 M-M 459
07300218
FITTING L 1/8 M-F 458
07300243
FITTING 1/4M 1/8M GIGLER F.0,5
07300244
FITTING 1/4M 1/8M + THREADED M8 Aisi303
07300777
S/S EXTENSION 1/8M 1/8F
07300858
FITTING 1/4M-1/4M OT-57 USA
07300864
FITTING 1/4M 1/8M + THREADED M6 Aisi316 +
09500024
MANUAL THERMOSTAT 135°C TRIP FREE GREEN DRIPPI
09500026
AUTOMATIC THERMOSTAT 110°C
14100096
RESISTANCE 3/4 600W 115V
14100098
HEATING ELEMENT 3/4 600W 230V INCOLOY800
98004016
S/S FILTER D12
980300000013000001
COFFEE BOILER ASSEMBLY 1GR. CE
980300000013000002
COFFEE BOILER ASSEMBLY 1GR. CSA
98030000002050
FLOWMETER T3 EXTERNAL GIGLER 0,5 SET
98031200
S/S WELDED COFFEE BOILER D42,5
98031264
COLD WATER CROSSPIECE
98031266
DOSER PIPE - COFFEE BOILER
98031272
COFFEE BOILER PIPE - DISPENSING GROUP
98110001
RETURN VALVE 1/8 F-FOT-58
98120001
NEPLAX VITON 16,5 BAR VALVE 1/8 HOSE CLAMP
14

Victoria Arduino EAGLE ONE PRIMA Specifications

General

Model	EAGLE ONE PRIMA
Category	Coffee Maker
Brand	Victoria Arduino
Type	Espresso Machine
Boiler Material	Stainless Steel
Voltage	220-240 V
Frequency	50/60 Hz
Steam Wand	Yes
Hot Water Tap	Yes
Group Heads	1
Material	Stainless Steel
Water Supply	Tank
Color Options	Black, White, Red
