Victoria Arduino EAGLE ONE PRIMA Service Manual

203
1
1
1
1
1
1
1
1
1
1
1
1
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
S
S
P
P
P
A
A
AR
R
R
E
E
E
P
P
PA
A
A
R
R
R
T
T
S
S
CODE DESCRIPTION END VALIDITY
0
00000233
GALVANIC WASHER M16 17x26x1
00300002
BRASS NUT 1/4 D3 CH18
01000023
ANTI VACUUM VALVE
01000629
STEAM BOILER INSULATION
02280032
GASKET O RING 114 D15 EP 851
02290034
GASKET O RING 6187 D47x5,34 VITON FDA
03000202
CONDENSATION TRAY MASTER
07300012
FITTING 1/4 1/4M-1/4M Aisi316
04100081
SOL. VALVE 2 WAYS 1/8-1/8 100/120V 50/60HZ VITON F1.2
04100082
SOL. VALVE 2 WAYS 1/8-1/8 220-230V 50/60HZ VITON F1.2
05000063
SAFETY VALVE COVER PA6
07300001
L FITTING 1/8 M-M 459
07300004
FITTING 1/8-1/8 DIRECT GAS
07300009
NUT FITTING 1/4 GAS
07300051
FITTING T 1/4 M-M-M CYLINDER
07300063
CLOSED TERMINAL D11
07300121
FITTING L 1/4 M-M CYLINDER (Update 18.02.97)
07300227
BRASS WASHER D.26X13,5X1,5 ADD.5.06.03
07300864
FITTING 1/4M 1/8M + THREADED M6 Aisi316 +
09000002
SELF-LEVEL PROBE COMP. L = 105 WITH THROAT
09200028
PRESSURE GAUGE 2,7 BAR 16A 230V
09500015
HEATING ELEMENT THERMAL PROTECTION G5 184°C 16
14100103
SS FLANGE RESISTANCE 1200W 115V
14100104
SS FLANGE RESISTANCE 1600W 230V
14100105
SS FLANGE RESISTANCE 1600W 115V
40000010
NUT M6 W/ WELDED GALVANIC WASHER
78030086
LEVEL SOLENOID PIPE PREMIER '01 AURELIA II DGT/T3/CSA
98013026
SAFETY VALVE D7-S 3 BAR 1/4" VITON 97/23/EC
980300000013010000
BOILER SET EAGLE ONE 1GR
98031201
STAINLESS STEEL WELDED BOILER D.114.3
98031262
SELF-LEVELLING PIPE
98031270
BOILER PIPE - CSA PRESSURE SWITCH
98031282
HOT WATER DRAFT HOSE
14

Victoria Arduino EAGLE ONE PRIMA Specifications

General

Model	EAGLE ONE PRIMA
Category	Coffee Maker
Brand	Victoria Arduino
Type	Espresso Machine
Boiler Material	Stainless Steel
Voltage	220-240 V
Frequency	50/60 Hz
Steam Wand	Yes
Hot Water Tap	Yes
Group Heads	1
Material	Stainless Steel
Water Supply	Tank
Color Options	Black, White, Red
