Victoria Arduino EAGLE ONE PRIMA Service Manual

205
1
1
1
1
1
1
1
1
1
1
1
1
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
S
S
P
P
P
A
A
AR
R
R
E
E
E
P
P
PA
A
A
R
R
R
T
T
S
S
CODE DESCRIPTION END VALIDITY
0
00000133
S/S CLIP WD12 16-25 C7 W2
01000092
3/8F-3/4F90D WATER CHARGE PIPE 1,5mt + FILTER
01000127
DIRECT SLEEVE DISCHARGE TUBE D19 L=2m
02280018
RED SILICON GASKET O RING Sh70
03003951
FRAME BASE
03003956
REAR UPPER SHEET
03003968
WATER TANK SUPPORT
03003974
LEFT GUIDE SHEET EAGLE ONE 1GR
03003976
CONTROL UNIT SUPPORT
03003978
ELECTRICAL PARTS SUPPORT
04001170
PRESENCE TANK SENSOR
04100042
2WAY SOLENOID 1/8-1/8 220-230V50/60Hz F2 CE
04100043
2WAY SOLENOID 1/8-1/8 110-120V 60Hz F2 UL TH1xM4
05000015
TUBE FASTENING WES 6R 1/8
05000658
FLAT WATER DRIP TRAY EAGLE ONE
05000668
CAPACITIVE PRESSURE SWITCH SUPPORT
05000759
WATER TANK COLLECTOR 5LT MICROBAR
05000761
STRAIGHT FITTING 3/4 Fx19 FOR EXHAUST PIPE
05340013
SMALL BASE 19X19 FOR BAND WITH SCREW HOLE M4
06100301
FOOT MACHINE
07300715
T FITTING 1/8 M -FITTINGS.6 -FITTINGS.6
08000003
HOSE CLAMP D9,1
11600001.W
WHITE SILICONE PIPE 4x7,5 60Sh (1mt=41gr)
98200000000030
1,5LT WATER TANK SET
14

Victoria Arduino EAGLE ONE PRIMA Specifications

General

Model	EAGLE ONE PRIMA
Category	Coffee Maker
Brand	Victoria Arduino
Type	Espresso Machine
Boiler Material	Stainless Steel
Voltage	220-240 V
Frequency	50/60 Hz
Steam Wand	Yes
Hot Water Tap	Yes
Group Heads	1
Material	Stainless Steel
Water Supply	Tank
Color Options	Black, White, Red
