CODE DESCRIPTION END VALIDITY
0
04000023
SUPPLY CABLE UL AWG3X16 USA PLUG SHEATH 90°C 30
04000126
ELECTRIC CABLE 2MT CE SCHUKO PLUG 90° 3X1,5
04000244
3POLE CONN CABLE RAST 2.5 / MOLEX L = 800mm
04000468
TRANSFORMER 24VDC 50W OPTIONAL
04000470
12VDC LED SPOT AURELIA WAVE
04001128
WIRING 115 HIGH VOLTAGE
04001130
WIRING 230 HIGH VOLTAGE
04001131
WIRING LOW VOLTAGE
04001144
SUPPLYING WIRING EASY CREAM 1GR.
04001156
CSA THERMAL DISJUNCER
04001161
LED STRIP 1GR EAGLE ONE
04001170
PRESENCE TANK SENSOR
04001172
CONN. CABLE TANK SENSOR- CONTROL UNIT
04001174
WI-FI MODULE CABLE- CONTROL UNIT
04200007
POWER RELAY 30A 230V BIPOLAR
04200009
POWER RELAY 30A 115V BIPOLAR
04200096
STATIC RELAY 25A 250V 1OUT
04200112
RED LIGHT 0/1 BIPOLAR SWITCH UL 16A
04901132
WI-FI MODULE
04901521
CONTROL UNIT EAGLE ONE 1GR. USA/CAN - AUS/NZ
04901522
CONTROL UNIT
14

Victoria Arduino EAGLE ONE PRIMA Specifications

General

Model	EAGLE ONE PRIMA
Category	Coffee Maker
Brand	Victoria Arduino
Type	Espresso Machine
Boiler Material	Stainless Steel
Voltage	220-240 V
Frequency	50/60 Hz
Steam Wand	Yes
Hot Water Tap	Yes
Group Heads	1
Material	Stainless Steel
Water Supply	Tank
Color Options	Black, White, Red
