3.3.1 DISASSEMBLE THE REAR PANEL
The rear panel of E1 PRIMA can be person-
alized.
To proceed it is necessary to disassemble it,
as it follows.
1
Remove the rear panel as described in
the previous paragraph.
2
Utilizing a Philips screwdriver, remove the
three screws and take off the eagle.
3
Utilizing a 8 mm wrench, remove the six
screws and disassemble the panel.
