Victoria Arduino MYTHOS 2 Service Manual

3.3MYTHOS 2
3 Utilising a Phillips screwdriver, loosen the two
screws that lock the rear part.
4 Pull the rear part toward the rear of the machine
and then downwards to r
elease it.
5 Disconnect the electrical wiring of the cooling fan.
Now, is possible to remove the r
ear part from the
machine.
NOTE
Into the rear part of the machine are
installed the two cooling fans.
NOTE
The cooling fans are activated to keep
the motor temperature below the
value chosen in the setting "MOTOR
TEMPERATURES" (see the relevant
description into the User Manual) and
for the second chosen in the setting
"FANS TIME", each time a dose of cof-
fee is ground.
5
1
2
6
7
8
