Victoria Arduino MYTHOS 2 Service Manual

6.1MYTHOS 2
ELECTRIC COMPONENTS
INDEX
6. ELECTRIC COMPONENTS ..................................... 6.1
6.1 MAIN BOARD.............................................................. 6.2
6.1.1 FUSES ........................................................................6.2
6.1.2 MAIN BOARD CONNECTIONS ....................................................6.3
6.2 DISPLAY BOARD........................................................... 6.3
6.2.1 DISPLAY BOARD CONNECTIONS .................................................6.3
6.2.2 GRAVIMETRIC SENSOR PLUG ....................................................6.4
6.3 GRINDER MOTOR TEMPERATURE PROBE .................................... 6.4
6.4 GRINDING CHAMBER TEMPERATURE PROBE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.5
6.5 INFRARED SENSORS....................................................... 6.5
6.5.1 REMOVAL OF THE SENSORS .....................................................6.6
6.6 REMOVAL OF THE MAIN SWITCH ............................................ 6.7
6
6
