Victoria Arduino MYTHOS 2

5.3MYTHOS 2
5.2 REMOVAL OF THE
GRINDER MOTOR
After accessing the grinder motor:
1 Remove the motor support, by loosing the two
screws utilising a 10mm key
.
2 Loosen the four silent block on the front of the
machine.
3 Slide out the motor from the rear of the machine.
4
5
6
