Victoria Arduino MYTHOS 2 Service Manual

11.4 MYTHOS 2
COD. DESCRIPTION DESCRIZIONE
END
VALIDIT
Y
00000011 STAINLESS STEEL KNURLED WASHER D4 RONDELLA INOX M4 ZIGRINATA UNI 8842/A
00000017 ZINC COATED NUT AQ M6 HIGH DADO AQ M6 ALTO ZINC. h6 5587
00000060 M3 MEDIUM GALVANISED NUT DADO AQ M3 MEDIO ZINCATO
00000089 SS CROSSHEAD CAP SCREW M4x12 VITE INOX M4x12 TC TCR DIN7985
00000113 SS CROSSHEAD CAP SCREW M4x6 VITE INOX M4x6 TC T.CR.7985
00000119 SS CROSS HEAD COUNTERSUNK SCREW M4x6 VITE INOX M4x6 TSPTCR ISO 7046
00000122 GALV. FLANGED KNURLED HEX CAP SCREW 8.8 M6x12 VITE AQ 8.8 M6x12
TE FLANG.ZIGR. ZINC. BIANCO
00000134 SCREW AQ M3x6 TC TC ZINC. UNI 6107 VITE AQ M3x6 TC TC ZINC.UNI6107
00000135 GALV. SLOTTED CAP SELF-TAPPIN SCREW 2,9x15 VITE AUTOF 2,9x15 TCTC ZIN.
00000160 STAINLESS WASHER D4X12 RONDELLA INOX D4x12x1 UNI 6593
00300019 STAINLESS STEEL DOWEL M4X8 5923 GRANO INOX M4x6 UNI 5923 PP
01000083 ANTI-VIBRATING DD 10X10 M4 ANTIVIBRANTE DD 10x10 M4
03003251 WEIGHT SCALE SHEET METAL SUPPORT LAMIERA SPESSORE SUPPORTO BILANCIA
04000198 FOIL HOLDER M 6.3 D 4.2 45° PRESA LAME
LLARE M 6.3 d4.2 45°
04480009 PLUG IEC F PRESA IEC DA INCASSO 3 POLI FASTON 6,3 10A FEMMINA
05000408 USB COVER VA 388 CHIUSURA PORTA USB
05000768 D13.5x6.6x1.5 BLACK PVC CABLE DUCT PASSAC. PVC NERO D13.5x6.6x1.5
05001350 MACHINE FOOT MASTER PIEDE MACCHINA D.40 H=18+GOMM. INSERTO M8 MASCHIO
05080037 MOTOR FOOT MASTER PIEDINO GOMMA DURA TONDO 9x5xh9
05340013 SMALL BASE 19x19 FOR BAND WITH SCREW HOLE M4 BASETTA 19x19 PER FASCETTA CON FORO PER VITE M4
05340017 BLACK WIRE CLAMP 135x2,6 FASCET. SERRAFILI 135x2,6 NERO
07300616 CASE M4 PIN PERNO CARENA M4
15000064 NUT STOPS GRINDER HOLDER DADO FERMA PORTAMACINE
15030002 SAFETY MICROSWITCH MYTHOS MICROSW SICUREZZA
15030027 60 µF CAPACITOR CONDENSATORE 60 mF UL
15030048 COMPLETE GUILLOTINE MYTHOS GHIGLIOTTINA COMPLETA
15030058 SS SCREW M3X6 VITE INOX M3x5 TSP TCR
15030085 GRINDER ASSEMBLY SCREW M4X10 VITE INOX M4x10 TCT(-) TESTA TAGLIO FISS. MACINE
15030087 VIBRATION DAMPER 20x15 M6 M/F ANTIVIBRANTE D20xH15xL16 M6 M/F
15030094 MYTHOS ONE CARTRIDGE HEAT. ELEMENT 220V RESISTEN
ZA + PRESA 220V
15030095 MYTHOS ONE MICROSWITCH MICROSW ATTIV. MACIN.
15030096 MYTHOS ONE CARTRIDGE HEAT. ELEMENT 110V RESISTENZA + PRESA 110V
15030098 MYTHOS ONE GRINDER REGISTER HANDLE POMELLO REGISTRO MACIN.
15030131 SS SCREW M6X16 VITE INOX M6x16 TSP T.CR.
15030137 MICRO ACTIVATOR GUIDE NUT DADO X DADO GUIDA MICRO ATTIV. MACIN.
15030149 "VICTORIA ARDUINO" LABEL ETICHETTA "VICTORIA ARDUINO"
15030150 "NUOVA SIMONELLI" LABEL ETICHETTA "NUOVA SIMONELLI"MYTHOS 2 E109-NS
15030151 "N.S. MYTHOS 2" LABEL ETICHETTA LOGO MYTHOS 2 N.
S. E110-NS
15030152 "V.A. MYTHOS 2" LABEL ETICHETTA LOGO MYTHOS 2 V.A. E110-VA
15030153 "NUOVA SIMONELLI" COFFEE BELL LABEL ETICHETTA FRONTALE CAMPANA "NUOVA SIMONELLI"
15030154 "VICTORIA ARDUINO" COFFEE BELL LABEL ETICHETTA FRONTALE CAMPANA "VICTORIA ARDUINO"
15030155 CLUMP CRUSHER SHEET FRANGIA CLUMP CRUSHER 0,25
15030157 MYTHOS 2 FORK FORCELLA MYTHOS 2
15030158 FILTERHOLDER SUPPORT BRACKET STAFFA REGGI PORTAF. REGOL.
15030159 "MZ" FILTERHOLDER FORK GROUP GRUPPO FORCELLA MYTHOS 2 PER PORTAFILTRO "MZ"
15030161 COMPLETE BELL "N.S
." CAMPANA COMPLETA "N.S."
15030162 COMPLETE BELL "V.A." CAMPANA COMPLETA "V.A."
15030163 COFFEE BELL COVER COPERCHIO CAMPANA
15030164 COMPLETE ENGINE VARIABLE SPEED MOTORE COMPLETO MYTHOS 2 GIRI VARIABILI
15030165 COMPLETE ENGINE FIXED SPEED 220V MOTORE COMPLETO MYTHOS 2 GIRI FISSI 220V
15030166 COMPLETE ENGINE FIXED SPEED 110V MOTORE COMPLETO MYTHOS 2 GIRI FISSI 110V
15030167 RELAY KIT FOR ENGINE FIXED SPEED 110V KIT RELE' MYTHOS 2 PER MOTORE GIRI FISSI 110V
15030168 SCALE GROUP GRUPPO BILANCIA
15030169 WEIGHT SCALE FILTERHOLDER SUP
PORT SUPP. PORTAF. BILAN.
15030170 WEIGHT SCALE SUPPORT SUPP. BILANCIA
15030171 COFFEE PRESENCE SENSORS GROUP GRUPPO SENSORI PRESENZA CAFFE'
15030172 RIGHT GRAIN SENSOR SUPPORT SHEET LAMIERA SUPP. SENSORI GRANO DX -TX
15030173 LEFT GRAIN SENSOR SUPPORT SHEET LAMIERA SUPP. SENSORI GRANO SX -RX
15030174 RIGHT TX GRAIN LEVEL SENSOR SENSORE TX PER LIVELLO GRANO (LATO DX)
15030175 LEFT RX GRAIN LEVEL SENSOR SENSORE RX PER LIVELLO GRANO (LATO SX)
15030176 SENSORS CABLE CAVO COLL. SENSORI PRESENZA CAFFE' CAV43
15030177 INVERTE
R IC 400 ASSIEME INVERTER IC 400 (110V- 220V)
15030178 INVERTER CABLE CAVETTO INVERTER CAV40
15030180 MAIN GROUP VARIABLE SPEED 220V GRUPPO CENTR. GIRI V. 220V
15030181 MAIN GROUP VARIABLE SPEED 110V GRUPPO CENTR. GIRI V. 110V
15030182 220V POWER SUPPLY ALIMENTATORE 220V
15030183 110V POWER SUPPLY ALIMENTATORE 110V
15030184 CONTROL UNIT PROTECTIVE SHEET PROTEZIONE SCHEDA
15030185 UNDER-COFFEE BELL PROTECTION SHEET PROTEZ. SOTTOCAMPANA
15030186.B MYTHOS 2 BASE WHITE BASAMENTO MYTHOS 2 BIANCO
15030186.NO MYTHOS 2 BASE BLACK BAS
AMENTO MYTHOS 2 NERO OPACO
15030187.B MYTHOS 2 BACK COVER WHITE CORPO POSTER. MYTHOS 2 BIANCO
15030187.NO MYTHOS 2 BACK COVER BLACK CORPO POSTER. MYTHOS 2 NERO OPACO
15030188.B MYTHOS 2 FRONT COVER WHITE PANNELLO FRONT. BIANCO
15030188.NO MYTHOS 2 FRONT COVER BLACK PANNELLO FRONT. NERO
