Victory CLASSIC User Manual

BOTTOM VIEW
SIDE VIEWFRONT VIEW
TOP VIEW
2 ¾”
10 ¼”
11 ⅜”
19 ¾”
Chimney
height
adjustable
from 23”
to 39 ½”
12”
12 ¾”
13”
11 ½”
Available sizes: 23 ½”, 29 ½” and 35 ½”
Ø 6”
Height from housing of range
hood to top of transtion: 12 ½”
Height from bottom of range
hood to top of transtion
: 15 ¼”
Height from bottom of range
hood to installation holes:
13 ¼”
VICTORY range hoods
| CLASSIC / PLANE
10
VICTORY range hoods
CLASSIC / PLANE |
11
DIMENSIONS
(
PLANE
)

Victory CLASSIC Specifications

General

Depth	50 cm
Material	Stainless Steel
Number of Motors	1
Lighting	LED
Filter Type	Aluminum
