Page #7 background imageLoading...
Page #7 background image
To calculate the length of the duct system you require, subtract the equivalent feet for each “Duct
piece” (Table Below) used in the system from the “Recommended maximum run” (Table Below).
The longest duct run that is acceptable (if completely straight) is 50 feet. The number of duct pieces
(elbow, transition, etc.) installed in your duct run will determine the maximum length the duct run can
be. Please refer to the example below:
Duct Run Calculation:
Recommended maximum run
6” round duct 50 ft
Duct piece deduction
Each 90º elbow used 9 ft
Each 45º elbow used 5 ft
Each 6” to 3/14 x 10” transition
used
7 ft
Side wall cap with damper 7 ft
Roof cap 7 ft
Duct Run Calcuation example:
One roof cap, two 90º elbows, and one 45º elbow
used:
7ft + 9ft + 9ft + 5ft = 30ft used.
The above duct pieces used are equivalent to 30ft
of a straight duct run. Subtract 30ft from the al-
lowable 50ft. The remaining distance of 20ft is the
longest that the straight ducting (in addition to the
duct pieces) can be.
Body Stainless Steel
Power Rating 120V/60Hz (USA & Canada standard)
General Input Power 120W + # of light x Voltage of light
Motor Input Power 120 W
Motor Revolution 800 RPM (±10%) to 1300 RPM (±10%)
Levels Of Speed Control 3 Levels
Maximum Airow 600 CFM
Air Pressure 150 Pa (200 Pa Maximum)
Noise Level (dB / Sone) Approx 35 / 0.7 to 67 / 6.5 (Lowest to Highest Speed)
Motor Type Single Chamber Ultra Quiet
Fan Type Centrifugal / Sirocco
Control Type 3 Speed Mechanical Push Button Switches
Filtration Type Aluminium Filter
Illumination 2 x 35W GU10 Halogen, 120V (12V LED Optional)
Ducting Size Top 6” Round
Warranty 1 YEAR ( parts warranty )
* Subject to change without notice, please contact your local reseller for details.
VICTORY range hoods
| CLASSIC / PLANE
6
VICTORY range hoods
CLASSIC / PLANE |
7
CALCULATING DUCT SYSTEM LENGTH
SPECIFICATIONS*
