Victory RS - Sequence of Operations

User Manual for RS and RSA Refrigerators Victory
Rev. 07/24 Victory 13
ON OFF
COMPONENT OPERATION CONTROLLER ACTION OPERATION CONTROLLER ACTION
COMPRESSOR Compressor turns
on when the cabinet
temperature is above
the sum of the set
point and the dead
band
The Compressor
Contact is energized
Compressor turns
o when the cabinet
temperature is equal
to or less than the set
point
The Compressor
Contact is de-
energized
RTN400 terminals
10, 11
RTN400 terminals
10, 11
CONDENSER FAN The Condenser Fan
turns on when the
Compressor is running
The Condenser Fan
is wired directly to
the Compressor, not
through the controller
The Condenser Fan
turns o when the
Compressor is not
running
The Condenser Fan
is wired directly to
the Compressor, not
through the controller
EVAPORATOR FAN The Evaporator Fan
runs continuously.
When the unit is
plugged in and the
evaporator has
achieved it run set
limit,
The Evaporator Fan is
connected to control
relay.
The Evaporator Fan
runs continuously.
When the unit is
plugged in and the
evaporator has
achieved it run set
limit,.
The Evaporator Fan is
connected to control
relay.
RTN400 terminals 4, 5 RTN400 terminals 4, 5
FACE HEATER Face heater is on
when compressor is
running
The Compressor
Contact is energized
The Face Heaters
turn o when the
Compressor is not
running
The Face Heater
are wired to the
Compressor Contact
RTN400 terminals
10, 11
RTN400 terminals
10, 11
LIGHT The light will turn on
when the door is open
(solid door models
only) or light button is
pressed
The Light Contact is
energized
The light will turn
o when the door
is closed (solid door
models only) or the
light button is pressed
The Light Contact is
de-energized
RTN400 terminals
13,14
RTN400 terminals
13,14
Condition Compressor Condenser Fan Evaporator Fan Lights
Cabinet Temp > Set point + Dead band ON ON ON ON or OFF
Cabinet Temperature <= Set point OFF OFF ON ON or OFF
Defrost OFF OFF OFF ON or OFF
SEQUENCE OF OPERATIONS
