Model
Cabinet Dimensions
w x d x h (Inches)
Sections
Half
or Full
Door
Glass
or Solid
Door
Full
Load
Amps
Refrigerant Type /
Charge (g) / Charge (oz.)
RS(A)-2D-S1-PT-HC 52 1/8 x 38 5/8 x 84 1/8
2
Full Solid
6.5 R-290 / 150 / 5.29
RS(A)-2D-S1-PT-HD-HC 52 1/8 x 38 5/8 x 84 1/8 Half Solid
RS(A)-2D-S1-PT-G-HC 52 1/8 x 35 3/4 x 84 1/8 Full Glass
8.5
R-290 / 130 / 4.59
RS(A)-2D-S1-PT-HD-G-HC 52 1/8 x 36 x 84 1/8 Half Glass
R-290 / 150 / 5.29RS(A)-2D-S1-EW-PT-HC 58 3/8 x 38 3/4 x 84 1/8 Full Solid
6.5
RS(A)-2D-S1-EW-PT-HD-HC 58 3/8 x 38 3/4 x 84 1/8 Half Solid
RS(A)-2D-S1-EW-PT-G-HC 58 3/8 x 35 7/8 x 84 1/8 Full Glass
8.5 R-290 / 130 / 4.59
RS(A)-2D-S1-EW-PT-HD-G-HC 58 3/8 x 35 7/8 x 84 1/8 Half Glass
RS(A)-3D-S1-HC 77 3/4 x 34 7/8 x 84 1/4
3
Full Solid
RS(A)-3D-S1-HD-HC 77 3/4 x 34 7/8 x 84 1/4 Half Solid
RS(A)-3D-S1-G-HC 77 3/4 x 33 1/2 x 84 1/4 Full Glass
RS(A)-3D-S1-HD-G-HC 77 3/4 x 33 5/8 x 84 1/4 Half Glass
RS(A)-3D-S1-EW-HC 85 1/2 x 34 7/8 x 84 1/8 Full Solid
RS(A)-3D-S1-EW-HD-HC 85 1/2 x 34 7/8 x 84 1/8 Half Solid
RS(A)-3D-S1-EW-G-HC 85 1/2 x 33 3/8 x 84 1/8 Full Glass
RS(A)-3D-S1-EW-HD-G-HC 85 1/2 x 33 1/2 x 84 1/8 Half Glass
RS(A)-3D-S1-PT-HC 77 3/4 x 38 5/8 x 84 1/4 Full Solid
RS(A)-3D-S1-PT-HD-HC 77 3/4 x 38 5/8 x 84 1/4 Half Solid
RS(A)-3D-S1-PT-G-HC* 77 3/4 x 35 7/8 x 84 1/4 Full Glass
10.8 R-290 / 150 / 5.29
RS(A)-3D-S1-PT-HD-G-HC* 77 3/4 x 36 1/8 x 84 1/4 Half Glass
RS(A)-3D-S1-EW-PT-HC 85 1/2 x 38 3/4 x 84 1/8 Full Solid
8.5
R-290 / 130 / 4.59
RS(A)-3D-S1-EW-PT-HD-HC 85 1/2 x 38 3/4 x 84 1/8 Half Solid
RS(A)-3D-S1-EW-PT-G-HC* 85 1/2 x 35 7/8 x 84 1/8 Full Glass
10.8
RS(A)-3D-S1-EW-PT-HD-G-HC* 85 1/2 x 36 x 84 1/8 Half Glass
RS models have stainless steel liners; RSA models have aluminum liners. Height includes casters.
* These models have two refrigeration systems, charge numbers are for each system.
• All models will maintain product temperature between 36 and 38 degrees F. at the factory setting of 38.
0
F.
• All models are 115 volts, 60 Hz AC and are equipped with a NEMA 5-15P plug.
• ALWAYS REFERENCE YOUR EQUIPMENT DATA PLATE AMPS, REFRIGERANT AND REFRIGERANT CHARGE FOR THE
MOST UP TO DATE AND ACCURATE VALUES.
• There are no access valves on the refrigeration system.
• Ultra Glass doors are optional - for full Ultra Glass Doors change G to UG, for Ultra Glass half doors, change HG to HD-
UG.
