Victory STAR - Dimensions (Continued); Safety Warnings; Pre-Installation Checks

Model 48
3 ½”
10”
3”
19 ⅝”
20 ¾”
1 ¼”
39 ½”
47 ⅜”
45”
14 ⅛”
3 ½”
1”
12”
2”
8”- Ø
Duct
BEFORE INSTALLING THE RANGE HOOD, CHECK FOR PHYSICAL DAMAGES.
THIS RANGE HOODS COMES WITH A WIRE AND PLUG.
TEST THE HOOD BEFORE INSTALLATION.
If there is a grinding noise coming from the motor, DO NOT INSTALL IT, contact us as soon as possible.
VICTORY range hoods
| STAR
12
VICTORY range hoods
STAR |
13
DIMENSIONS
(
Continued
)
PREPARATION
