9
HOW TO REPLACE THE STYLUS
Guide Pins(inside)
The stylus should last about 50 hours under normal use. However, it is recommended that the
stylus be replaced as soon as you notive a change in sound quality.
Caution:
Do not remove or bend the sylus.
To avoid injury, do not touch the needle.
Turn off the unit's power before you replace the stylus.
Keep out of the reach of children.
record and cause the turntable stylus to malfunction.
Do not expose stylus to extreme heat.
Handle with care, as the stylus is delicate. Use of a bent or broken stylus may damage the
Contact a qualified repair company if you experience difficulty in changing the stylus.
1. Set a screwdriver at the tip of the stylus and push down to the direction "A".
2. Pull the stylus out toward direction "B".
1. Hold the tip of the stylus and insert the other edge by pressing toward direction "C".
2. Push the stylus up toward direction "D" until it locks at the tip.
Removing an old stylus:
