Victron energy MultiPlus 12 User Manual

18
ds2=on
ds3=on
15.0
30.0
60.0
13.8
27.6
55.2
13.2
26.4
52.8
6
Tubular plate or
OPzS batteries in
cyclic mode
Ds4: Inverter frequency off = 50Hz on = 60Hz
Ds5: Search Mode off = off on = on
Store the settings by moving DIP switch 6 to ‘on’ and back to ‘off’.
5.4.3 Exemplary settings
Example 1 is the factory setting (since factory settings are entered by computer, all DIP
switches of a new product are set to ‘off’).
DS-1 3 position switch
off
DS-2 Charge voltage
off
DS-3 Charge voltage
off
DS-4 Frequency
off
DS-5 Search mode
off
DS-6 Store setting
→
←
DS-1
off
DS-2
on
DS-3
off
DS-4
off
DS-5
off
DS-6
→
←
DS-1
on
DS-2
on
DS-3
on
DS-4
on
DS-5
on
DS-6
→
←
Example 1: (factory setting)
1 No 3 position
switch connected
2, 3 GEL 14.4 V
4 Frequency: 50Hz
5 Search mode off
6 Store setting: off→ on→ off
Example 2
1 No 3 position
switch connected
2,3 AGM 14,7V
4 Frequency: 50Hz
5 Search mode off
6 Store setting: off→ on→ off
Example 3
1 3 position
switch connected
2, 3 Tubular plate 15V
4 Frequency: 60Hz
5 Search mode on
6 Store setting: off→ on→ off
Store the settings by changing switch ds-6 from off to on, and then back to off.
The LEDs ‘charger’ and ‘alarm’ will flash to indicate acceptance of the settings.
6. MAINTENANCE
The Multi does not require specific maintenance. It will suffice to check all connections once a
year. Avoid moisture and oil/soot/vapours, and keep the device clean.
