Victron energy MultiPlus 12 User Manual

21
EN NL FR DE ES IT Appendix
8. TECHNICAL DATA
12 Volt
24 Volt
48 Volt
MultiPlus 12/500/20
MultiPlus 24/500/10
MultiPlus 48/500/6
MultiPlus 12/800/35
MultiPlus 24/800/16
MultiPlus 48/800/9
MultiPlus 12/1200/50
MultiPlus 24/1200/25
MultiPlus 48/1200/13
PowerControl / PowerAssist Yes / No Yes / Yes
Transfer switch 16A
INVERTER
Input voltage range 9,5 – 17V 19 – 33V 38– 66V
Output Output voltage: 230VAC ± 2% Frequency: 50Hz ± 0,1% (1)
Cont. output power at 25°C (3) 500VA 800VA
1200VA
Cont. output power at 25°C 430W 700W
1000W
Cont. output power at 40°C 400W 650W
900W
Cont. output power at 65°C 300W 400W
600W
Peak power 900W 1600W
2400W
Maximum efficiency 90 / 91 / 92% 92 / 93 / 94%
93 / 94/95%
Zero-load power 6 / 6 / 7W 7 / 7 / 8W
10 / 9 / 10W
Zero-load power in search mode 2 / 2 / 3W 2 / 2 / 3W 3 / 3 /3W
CHARGER
AC Input Input voltage range: 187-265 VAC Input frequency: 45 – 65 Hz
Charge voltage 'absorption' 14,4 / 28,8 / 57,6V
Charge voltage 'float' 13,8 / 27,6 / 55,2V
Storage mode 13,2 / 26,4 /52,8V
Charge current house battery (4) 20 / 10 / 6A 35 / 16 / 9A 50 / 25 / 13A
Charge current starter battery 1 A (12V and 24V models only)
Battery temperature sensor
Yes
GENERAL
Programmable relay (5) Yes
Protection (2) a – g
Common Characteristics
Operating temp. range: -40 to +65°C (fan assisted cooling)
Humidity (non-condensing): max 95%
ENCLOSURE
Common Characteristics Material & Colour: Steel/ABS (blue RAL 5012) Protection category: IP 21
Battery-connection 16 / 10 / 10 mm² 25 / 16 / 10 mm² 35 / 25 / 10 mm²
230V AC-connection G-ST18i connector
Weight 4,4 kg 6,4 kg 8,2kg
Dimensions (h x w x d) 311 x 182 x 100 mm 360 x 240 x 100 mm 406 x 250 x 100 mm
STANDARDS
Safety EN-IEC 60335-1, EN-IEC 60335-2-29, EN 62109-1
Emission / Immunity
EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3
IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
Road vehicles ECE R10-4
1) Can be adjusted to 60Hz and to 240V
2) Protection
a. Output short circuit
b. Overload
c. Battery voltage too high
d. Battery voltage too low
e. Temperature too high
f. 230VAC on inverter output
g. Input voltage ripple too high
3) Non-linear load, crest factor 3:1
4) At 25°C ambient
5) Programmable relay which can be set for:
general alarm, DC under voltage or generator start/stop signal function
AC rating: 230V/4A
DC rating: 4A up to 35VDC, 1A up to 60VDC
