4. INSTALLATION
4.1 Location
The product must be installed in a dry and well-ventilated area, as close as possible to the
batteries. There should be a clear space of at least 10cm around the appliance for cooling.
For mounting see G
For safety purposes, this product should be installed in a heat-resistant
environment. Prevent the presence of e.g. chemicals, synthetic components,
curtains or other textiles, etc., in the immediate vicinity.
4.2 Connection of the Battery cables
In order to fully utilize the full capacity of the product, batteries with sufficient capacity and
battery cables with sufficient cross section should be used. See table below:
12/500/20
24/500/10
48/500/6
12/800/35
24/800/16
48/800/9
Recommended
cross section (mm
2
)
1,5  5 m
16
10
6
25
16
10
Recommended
battery capacity (Ah)
60 – 300 30 - 150 20 – 100 100 - 400 40 - 200 25 - 150
12/1200/50
24/1200/25
48/1200/13
Recommended
cross section (mm
2
)
1,5  5 m
35
25
10
Recommended
battery capacity (Ah)
150 – 700 70 - 400 35 – 200
This product should be installed by a qualified electrician.
a. Excessively high ambient temperature will result in the following:
- Reduced service life.
- Reduced charging current.
- Reduced peak capacity, or shutdown of the inverter.
b. Never mount the product directly above the batteries.
