8. TECHNICAL DATA
MultiPlus Compact
12 Volt
24 Volt
C 12/800/35
C 24/800/16
C 12/1200/50
C 24/1200/25
C 12/1600/70
C 24/1600/40
PowerControl / PowerAssist Yes Yes Yes
Transfer switch (A) 16 16 16
INVERTER
Input voltage range (V DC) 9,5 – 17V 19 – 33V
Output
Output voltage: 230 VAC ± 2%
Frequency: 50 Hz ± 0,1% (1)
Cont. output power at 25°C (VA) (3) 800 1200 1600
Cont. output power at 25°C (W) 700 1000 1300
Cont. output power at 40°C (W) 650 900 1200
Cont. output power at 65°C (W) 400 600 800
Peak power (W) 1600 2400 3000
Maximum efficiency (%) 92 / 94 92 / 94 92 / 94
Zero-load power (W) 8 / 10 8 / 10 8 / 10
Zero load power in search mode (W) 2 / 3 2 / 3 2 / 3
CHARGER
AC Input
Input voltage range: 187-265 VAC
Input frequency: 45 – 65 Hz Power factor: 1
Charge voltage 'absorption' (V DC) 14,4 / 28,8
Charge voltage 'float' (V DC) 13,8 / 27,6
Storage mode (V DC) 13,2 / 26,4
Charge current house battery (A) (4) 35 / 16 50 / 25 70 / 40
Charge current starter battery (A) 4
Battery temperature sensor yes
GENERAL
Programmable relay (5) yes
Protection (2) a - g
Common Characteristics
Operating temp. range: -40 to +65°C
(fan assisted cooling)
Humidity (non condensing) : max 95%
ENCLOSURE
Common Characteristics
Material & Colour: aluminium (blue RAL 5012)
Protection category: IP 21
Battery-connection Battery cables of 1.5 meter
230 V AC-connection G-ST18i connector
Weight (kg) 10
Dimensions (hxwxd in mm) 375x214x110
STANDARDS
Safety EN 60335-1, EN 60335-2-29
Emission / Immunity EN55014-1, EN 55014-2, EN 61000-3-3
Automotive Directive
2004/104/EC
