32E66-13
Coaxial / RF Cable (not included)
TV REAR PANEL
Ant. / Cable
Wall Outlet
Installation
Connection to Antenna &
Cable / Satellite Box
Connecting to POWER IN
Roof Antenna / Cable Outlet Installation
We recommend using a high quality roof top antenna, digital cable, or satellite box for the best display and
performance.
Note: Reception quality is determined by your location, geographical terrain, distance form the local
broadcast transmitter, and strength of antenna.
Connecting an antenna or basic cable
service:
• Connect the RF coaxial (75 ohm) cable from
existing roof top / in door antenna, or wall outlet.
• Finger tighten the Coaxial / RF Cable end to the
TV input on the rear panel.
• See pages 20-21 for TV setup and Channel Auto
Scan.
How to connect with power cord
• Connect the power cord to a properly grounded AC outlet, then to your TV.
