Videocon Shine - 6-2. Disassembly Information - Assy-Gear Box

6. SERVICE INFORMATION
17
ITEM HOW TO DISASSEMBLE AND ASSEMBLE DRAWINGS
7.
(Fig 5)
(Fig 6)
(Fig 7)
NUT
BOLT
SHAFT-B
COUPLING
MOTOR
SPIN MOTOR
and
WASH MOTOR
Unscrew the screws from Base and Tub for all four sides.
(Fig. 6)
Screws
Screws
Lift the Tub upside holding from Handles and separate
Tub from Base (Fig. 6)
Handle
Handle
8.
6.
Lay down the machine of soft board placed on floor,
to avoid scratch or damage on machine. (Fig. 5)
turn a bolt to counterclockwise and removeit.(Fig. 7)
(Used tool boxdriver)
9.
Untighten a nut assembledto the BRAKE WHEEL,and
SCREW
FRAME-
BRAKE
SPRING
Using driver,disassemble three Brake frame
screws. (Fig 8)
10.
(Fig 8)
6-2. DISASSEMBLY INFORMATION
