SENTRY 1 CONTROL UNIT
Introduction
The information in this manual is intended as an installation and
commissioning guide for the sentry 1 system. This manual should be read
carefully before the installation commences. Any damage caused to the
equipment due to faulty installations where the information in this manual has
not been followed is not the responsibility of VIDEX security UK LTD.
Description
The sentry 1 system can be used as a one or two door audio or video system.
The system comprises of the functional door panels (with the required
number of buttons), a control cabinet, a lock release for each door and the
required number of handsets. The following optional extras can also be used
with the sentry 1 system :-
Fireman's switch•
Busy light•
Codelock•
Sentrykey•
Push to exit•
Door monitoring•
Extension speaker•
Extension strobe•
Battery discharge cut off PCB•
Isolation PCB•
Video•
VproX proximity system•
The sentry 1 system is a two door functional door entry system which can be
expanded to control more doors with the use of additional sentry 1 control
PCB’s (One required for every two doors).
The Door panel can consist of any number of buttons. The vandal resistant or
Brass door panels can be used with this system. The door panel will also
include a diode board which is used to indicate to the control PCB which door
the call has come from. The door panel can also be extended to include
optional extras (i.e. codelock, sentrykey, video etc).
The 431/B control consists of a 24 hour analogue time clock, a 1 amp PSU
and the sentry 1 control PCB all within a lockable cabinet. (There is also
room within the cabinet for a back up battery (max - 12V 7AH).
The 531/B control cabinet contains the same items as the 431/B, but is IP55
rated.
There is a large range of compatible audio Handsets the system will work
with, these are listed in this manual.
