27
You can call up help messages relating to the displays
and functions.
Tap the following on-screen buttons:
1. to call up the help messages.
2. to return to the previous screen.
Calling up information
Subject to the components connected and the settings
made, you can check current temperatures and oper-
ating conditions.
Single boiler constant control
The information is split into groups:
"General"
/ "Burner" (gas or oil)
"Heating"
"DHW"
"Solar energy"
"Service contact details"
"LAN"
"Reset data"
Note
Detailed options for checking the individual groups can
be found in chapter "Menu overview".
Control of a multi boiler system
The information is split into groups:
"General"
/ "Burner" (gas or oil)
"Service contact details"
"LAN"
"Reset data"
Tap the following on-screen buttons:
1. If required, for the home screen
2. for the "Main menu"
3. "Information"
Checking the solar thermal system energy yield
This check can only be made at the constant tempera-
ture control unit of a single boiler system.
Note
This information can only be retrieved in conjunction
with the solar control module, type SM1. When con-
nected to a Vitosolic solar control unit, you can call up
the solar energy yield on the Vitosolic.
Tap the following on-screen buttons:
1. If required, for the home screen
2. for the "Main menu"
3. "Information"
4. "Solar energy"
5. Only for the energy yield of the solar thermal
system:
"Solar energy bar chart"
Note
You can also call up the energy yield of the solar
thermal system in the "Energy cockpit".
Resetting operating data (meters)
You can reset the operating data (meters) to zero,
depending on the connected components.
Single boiler constant control
You can reset the following operating data to zero:
■
"Burner hours run"
■
"Burner starts"
■
"Solar circuit pump"
■
"Solar energy"
■
"SM1 output 22" (hours run)
■
"All data"
Calling up information
Calling up help messages
