Viessmann Vitocell 100-E - Fitting the Cover Strips (3-Part Thermal Insulation Jacket)

13
Fitting the cover strips (3-part thermal insulation jacket)
3.
2.
3.
3.
1.
4.
A
Fig. 9
A
Type plate
1. Fit the thermal insulation jacket evenly around the
cylinder body by patting it.
2. Cut out the perforated openings on the cover strips
to make way for the connections.
Installation sequence
Installation (cont.)
5694 385 GB
Installation
