Viessmann Vitocell 100-E - 3 Installation Sequence Installation; Levelling the Heating Water Buffer Cylinder

7
!
Please note
The thermal insulation must not come into con-
tact with naked flames.
Exercise caution when welding and brazing.
Levelling the heating water buffer cylinder
Note
Seal connections that are not required with caps.
A
B
3.
3x
4.
1.
2.
Fig. 3
A
Type plate
B
3 adjustable feet
3. Insert the adjustable feet into the legs as far as they
will go. Use the adjustable feet to level the cylinder.
Note
Never extend the adjustable feet beyond a total
length of 30 mm.
Installation sequence
Installation
5694 385 GB
Installation
