Viessmann Vitocell 100-E - 6 Specification Product Characteristics

25
Vitocell 100-E
Cylinder capacity l 1500 2000
Thermal insulation Standard
(2-part)
Highly effi-
cient
(3-part)
Standard
(2-part)
Highly effi-
cient
(3-part)
Standby heat loss
to EN 12 897: 2006
Q
ST
with 45 K temperature differ-
ential
kWh/24 h 3.7 2.9 4.55 3.2
Energy efficiency class C B C B
Dimensions
Length (7)
■
Incl. thermal insulation mm 1310 1400 1310 1400
■
Excl. thermal insulation mm 1100 1100 1100 1100
Width excl. thermal insulation mm 1280 1280 1280 1280
Height
■
Incl. thermal insulation mm 2051 2096 2479 2546
■
Excl. thermal insulation mm 1939 1939 2378 2378
Height when tilted excl. thermal
insulation and adjustable feet
mm 1967 1967 2402 2402
Weight
■
Incl. thermal insulation kg 217 224 253 265
■
Excl. thermal insulation kg 170 170 201 201
Connections (male thread)
Heating water flow and return R/G 2 2 2 2
Air vent valve R 1 1 1 1
Specification
Product characteristics
5694 385 GB
Appendix
