Type OC208
A Return
B Flow
C Hydraulic circuit
D Refrigerant circuit
1 Service valve, high pressure side
2 High pressure switch
3 Compressor
4 Low pressure switch
5 Service valve, low pressure side
6 Plate-type heat exchanger
7 Differential pressure switch
8 Air vent valve
9 Circulation pump, hydraulic circuit
qP Diaphragm expansion vessel
qQ Pressure gauge
qW Safety valve
qE Fill & drain valve
qR Expansion valve
qT Filter
qZ Air heat exchanger with fan
