Vitoclima 200-C Type OC212H OC215H
Refrigerant circuit
Process medium R 407 C
Fill volume kg 2.74 3.80
Compressor Type Scroll
Surface area (W x H) primary heat
exchanger
mm 1200 x 890 1200 x 890
Fans
No. 2 2
Air flow rate m
3
/h 5600 5500
Speed rpm 800 800
max. power consumption kW 0.3 0.3
Noise specification
Sound power level dB(A) 70 71
Sound pressure level
*
1
dB(A) 39 40
Dimensions and weight
Total length mm 400 400
Total width mm 1182 1182
Total height mm 1309 1309
Weight kg 158 160
Permissible operating pressure bar 3.0 3.0
Hydraulic
Flow connection R 1" 1"
Return connection R 1" 1"
Diaphragm expansion vessel (ca-
pacity)
l 5 5
Specification (units for cooling and heating . . . (cont.)
50
Specification (units for cooling and heating mode)
5692 696 GB
*1
Calculated value for a distance of 5 m.
