With cover
Fig. 7
For the meaning of LEDs "2", "3" and "4", see the fol-
lowing table "Display elements".
Without cover
To remove the cover, see page 8.
Fig. 8
"1" to "4" LEDs; for meaning see the following
table "Display elements"
"T1" to "T4" Buttons; for meaning see the following
table "Operating elements".
Display elements
Designation Status Meaning
LON service indicator
"1" Off Standard mode
Flashing green LON subscriber check was successful
Commissioning
Display and operating elements
