Viessmann Vitogate 200 - Commissioning; Display and Control Elements; Vitotronic Control Unit LON Integration

12
Designation Status Meaning
KNX/EIB service indicator
"2" Off Standard mode
Flashing red Physical KNX/EIB address is being checked via ETS
(EIB tool software)
Red Receiving physical KNX/EIB address and application
Display of KNX TP connection status
"3" Off KNX TP not active
Yellow KNX TP connected
Flashing yellow Data transmission active in KNX TP
Display for operating status
"4" Off No power supply
Flashing red Heating system fault
Green Standard mode
Flashing green Initialisation running
Flashing green quickly Installing software update.
Note
The device must not be disconnected from the power
supply.
Operating elements
Button Meaning
"T1" No function
"T2" Programming the physical KNX TP address for manual integration of the Vitogate 200,
type KNX into an existing KNX/EIB system
"T3" LON service for manual integration of the Vitogate 200, type KNX into an existing LON
"T4" Software reset: Vitogate is re-started.
Commissioning
Plug the power supply unit into a standard 230 V~
socket.
LED "4" flashes green; Vitogate 200, type KNX is
being initialised.
As soon as "LED 4" illuminates green, the Vitogate 200
is ready for operation.
Note on LON integration
When commissioning the Vitotronic control unit, the
Vitogate 200 is automatically recognised as a LON
subscriber (see the following chapter).
Integrating the Vitotronic control unit into LON
The LON communication module (accessory) must be
plugged into the Vitotronic control unit.
Vitotronic control unit installation and service
instructions
or
Communication module installation instructions
Note
The data transfer via LON can take several minutes.
Commissioning
Display and operating elements (cont.)
5673180
Commissioning
