Example 1: Adjustment of the stan-
dard room temperature from 20 °C to
26 °C
A Boiler water temperature or flow
temperature in °C
B Outside temperature in °C
C Set room temperature in °C
D Heating circuit pump OFF
E Heating circuit pump ON
2. Adjust the set day temperature with
rotary selector " ts".
The value will be automatically
accepted after approx. 2 s.
Accordingly, the heating curve is
adjusted along set room tempera-
ture axis C, which results in modi-
fied start/stop characteristics of the
heating circuit pumps if the heating
circuit pump logic is enabled.
Reduced room temperature:
1. In case of two heating circuits –
select the relevant one:
&
Press a.
&
"1r" flashes on the display.
&
Select heating circuit A1 (heating
circuit without mixer):
&
Press d.
&
Select heating circuit with mixer
M2:
– – Press a.
– – "2r" flashes on the display.
– – Press d.
Further details regarding the individual steps (cont.)
35
Initial start-up, inspection, maintenance
5692 536 GB
