Vitodens 100-W, WB1B Technical Data
Operation
Heating circuit pumps (continued)
DHW Production Planning
With the CombiPLUS for instantaneous DHW heating
or with DHW connections for DHW production via a
stand-alone DHW storage tank, the Vitodens 100 boiler
series offers the right solution for every need.
Various factors must be taken into account when
designing the DHW system, and when deciding between
the DHW production with integrated CombiPLUS and the
standard heating boiler with DHW production via a stand-
alone DHW storage tank.
Options
Gas-fired boiler
with
instantaneous
CombiPLUS
production
Gas-fired standard
heating boiler
with stand-alone
DHW storage tank
DHW requirement,
level of comfort and
convenience
DHW requirement for an apartment + +
DHW requirement for a single-family house 0 +
Central DHW requirement for a multi-family house - +
Decentralized DHW requirement for a multi-family house + +
Number of draw points One draw point + 0
Several draw points, non-simultaneous use + 0
Several draw points, simultaneous use - +
Distance of draw
points from the boiler/
DHW storage tank
Up to 23 ft. (7 m) (without DHW recirculation line) + -
With DHW recirculation line - +
System retrofit DHW storage tank already installed - +
Replacement of existing Combi boiler + -
Space requirements Minimal space available (installation in alcove) + 0
Adequate space available (boiler room) + +
+ (recommended)
0 (recommended in certain cases)
- (not recommended)
Such factors are:
g DHW requirement, level of comfort and convenience
g Number of draw points
g Distance of draw points from the boiler/DHW storage tank
g System retrofit
g Space requirements
