Viessmann WB1A007 Technical Data Manual

30
5601 189 v1.1
Vitodens 100-W, WB1B Technical Data
Single Pipe System
Venting
Sing
le pipe system (room air dependant) horizontally vented
Vent system
diameter (in)
2* 3 4
Maximum
equivalent
length ft. (m)
86 (20) 164 (50) 200 (61)
CPVC and stainless steel (field supplied)
PP(s) (Viessmann supplied)
S
ingle pipe system (room air dependant) vertically vented
Vent system
diameter (in)
2* 3 4
Maximum
equivalent
length ft. (m)
86 (20) 164 (50) 200 (61)
CPVC and stainless steel (field supplied)
PP(s)
(Viessmann supplied)
*stainless steel is not available in 2”
*stainless steel is not available in 2”
Flue
Intake
Intake
Flue
IntakeIntake
