ViewSonic CDE4302 User Manual

3
Ventilation Requirements for enclosure locating
To allow heat to disperse, leave space between surrounding objects as shown in the diagram below.
100 mm 100 mm
100 mm
100 mm
1.5. Using of Remote sensor and power indicator
1. Push left the lens to have better remote control performance and easy to observe the light information of
power status.
2. Push right the lens before mounting the display for video wall application.
3. Pull/Push the lens until hearing the click sound.
Push right to collapse the lens Push left to extend the lens

ViewSonic CDE4302 Specifications

General

Panel life	30000 h
Panel type	TFT
Matrix type	-
Response time	6.5 ms
Display diagonal	43 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	109 cm
Active display area (W x H)	940.9 x 529.25 mm
Console port	RS-232
Package weight	12.2 kg
Quick start guide	Yes
RS-232 input ports	1
Network controllable	RS232
Depth (without stand)	59.9 mm
Weight (without stand)	8700 g
USB version	2.0
HDMI version	1.4
USB connector type	USB Type-A
Orientation	Horizontal
Product color	Black
Product design	Digital signage flat panel
Panel mounting interface	200 x 200, 400 x 400 mm
RMS rated power	20 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	105 W
12200 g	Weight of the packaged product in gram.
Package depth	159 mm
Package width	1070 mm
Package height	696 mm
Cables included	AC, RS-232, VGA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Width	968.2 mm
Height	559.4 mm
