ViewSonic Corporation Confidential - Do Not Copy PJ503D-1
TABLE 2 :
產品一般外觀的塑膠件檢驗標準
(General Product of plastic outlook inspection standard)
NO Appearance Spec
1
縮水
Shrinkage
A 區: 不可有縮水 , 以帶手套檢驗, 手摸過去不可有凹陷的感覺
A region: No Shrink. With gloves, no feeling of sink when touching the surface
B / C 區: 不能明顯看出
B/C region: not obvious
2
流痕, 咬花, 光澤
Run, Texture,
Gloss
不能有明顯的深淺不均
No obvious non-uniformity
3
接合線
Welding Line/Knit
Line
用指甲劃過不會有停頓感,並附近無明顯之光澤差異
When scratching on it, there’s no feeling of obstruction. Also, there should not
be obvious difference in gloss nearby it.
4
頂白
Ejector Mark
不可
Reject
5 Label/screws
shortage
不允許
Reject
6
缺料
Material shortage
缺料不可影向機構強度和表面
Material shortage is not allowed to impact structure strength and surface
7
色差
Chromatic
aberration
噴漆(Painting): ΔE<=2; L<=1.5 ; Δ A,B <= 0.6
銀粉漆 (Paint, aluminum).
ΔE<=2 L<=1.0; Δ A, B <= 0.6
非銀粉漆(Paint, non-aluminum)
素材(Raw material) : ΔL,A,B<=0.6 ,ΔE<=0.75
8
印刷
Printing
文字印刷不得有漏印、斷線、重影、組細不均、溢墨、印偏( 2mm )、印斜 (歪
斜＜0.5 mm )。
Printing must not have incomplete printing, break off, overlap, uneven
thickness, excessive ink, printing misalignment (2mm), printing slanting &
crooked (<0.5mm)
文字印刷顏色須確認是否正確 。
Printing color must be comparable to color chip and sample.
9 Logo of panel
sticker
文字印刷不得有漏印.斷線.重影.組細不均.溢墨.印偏( 2mm)印斜 (歪斜 ＜ 0.8
mm).
Printing must not have incomplete printing, break off, overlap, uneven
thickness, excessive ink, printing misalignment (2mm), printing slanting &
crooked (<0.8mm)
文字印刷顏色須確認是否正確.
Printing color must be comparable to color chip and sample.
10
刮傷
Scratch/Nicks
Side A
:
(W < 0.2mm , L < 5mm): 容許 2 個
Only 1 this kind of scratch is accepted
W < 0.1mm , L < 5-10mm 容許 1 個
No this kind of scratch is accepted
9
