ViewSonic Corporation Confidential - Do Not Copy PJ503D-1
3. Optical Engine Assembly Concerns
1. Assembly Lamp module:
1.1 BKT Baffle , Baffle Lamp , Fin and Mesh Assembly
I. Assemble BKT Baffle with Lamp holder (Figure 1-1) 。
II. Assemble “Baffle lamp” with Lamp holder and alight screw holes with holder first.
(Figure 1-2)。
III. Assemble “assembly of Fin_Mesh” on Baffle first and fasten the screw (Figure 1-3)。
IV. Hook “Mesh” on the Lamp Holder first and fasten the screw (Figure 1-4)。
V. To make sure that “Assembly of Fin_Mesh” on the right side when you face to the Baffle
(Figure 1-5)。
Figure 1-1
Figure 1-2 Figure 1-3
Baffle Lamp
Lamp Holder
M2*4L screw
Hook on the Holder
Lamp Holder
BKT Baffle
M2*4L screw
