ViewSonic PJ503D-1 - Appendix

126
ViewSonic Corporation Confidential - Do Not Copy PJ503D-1
Appendix 1 – Screw List /Torque
Model name : PJ503D
Description Torque Where use
No. Screw P/N
Type Head Length Coating
Q’TY
(kgf-cm)
Engine HSG & Power BD shielding (1*)
1 8F.1G524.5R0 MACH CAP 5 NI 2 4~5
EMI mylar wire & Power BD shielding (1*)
Blower BKT BTM & LOWER CASE(2*)
Ballast & Lower case(4*)
Ceiling mount plate & Lower case(3*)
Lamp wire holder & LOWER CSAE(1*)
Power Board S/W & LOWER CSAE(2*)
2 8F.VA564.6R0 TAP PHM 6 NI 14 5~6
Lamp Box & LOWER CSAE(2*)
3 8F.1A524.8R0 MACH PHM 8 NI 2 4~5
LAMP DOOR & LOWER CASE (2*)
Blower BKT & Nozzle(1*)
4 8F.1A524.5R0 MACH PHM 5 NI 6 4~5
Main BD shielding & Power BD
shielding(5*)
5 8F.VA564.100 TAP PHM 10 NI 4 5~6
Upper case & Lower case(4*)
6 8F.VG524.8R0 TAP CAP 8 NI 3 5~6
Lower case & Power BD shielding (3*)
7 8F.VA564.8R0 TAP PHM 8 NI 3 5~6
Engine HSG & Lower case(3*)
M3.0
8 8G.00020.423 NUT HEX 3 NI 1 2~3
Rear adjust foot top(1*)
M2.0
1 8F.1A522.6R0 MACH PHM 6 NI 1 2~3
Holder adjust foot & Fix block (1*)
AC Wire & Power BD shielding(1*)
M4.0
1 8F.1D526.6R0 MACH TAPTILE 8 NI 4 5~6
Ceiling mount plate & Lower case(3*)
#4-40
1 8F.00480.120 MACH STAND 8 NI 2 4~5
Rear case & D-SUB(2*)
11. Appendix
