ViewSonic PJ503D-1 - Page 130

127
ViewSonic Corporation Confidential - Do Not Copy PJ503D-1
Appendix 2 –Recommand Spare parts List
Description Ref. P/N Description
6E.01202.001 ASSY PL ZOOM MP510 CANON
CS.5J03A.001 PACK CW MODULE PJ503D
CS.5J03A.011 PACK LP MODULE PJ503D
7A.08060.B01 IC DMD 0.6SVGA S8060-6409
Optical
Components
5J.03A01.001 PACK LAMP MODULE RLC-030
6K.01222.001 ASSY SUB LAMP DOOR MP510
6K.03A03.011 ASSY UPPER CASE PJ503D
6K.03A05.001 ASSY LOWER CASE VG30
6K.03A06.011 ASSY CASE FRONT PJ503D
6K.03A07.001 ASSY CASE REAR VG30
Cabinets:
[Front Panel,
Back Cover,
Base]
6K.03A08.001 ASSY CAP LENS VG30
2C.10103.091 FAN*2 80*80/70*70*25 AD0812HB
Hardware:
2C.10102.041 FAN 50*20 170MM AB5012MB MP510
5E.01240.001 PCBA POWER BD MP510 MI
5E.03A01.011 PCBA MAIN BD VG30 VS MI
5E.J2C02.001 PCBA DMD CHIP BD MP611 MI
PC Board
Assembly:
[All PCBA]
5D.01212.001 BALLAST 160W PHG161G9 MP510
2G.01111.101 CORD SVT 125V 1.8M PVC-80P US
2G.01018.000 CORD SVT 125V 1.8M PVC-80P UK
2G.82718.281 CORD SVT 125V 1.8M PVC-80P EU
2G.01343.001 CORD SVT 125V 1.8M PVC-80P AU
2G.04246.001
CORD SVT 125V 1.8M PVC 80P CN
5K.01207.501 CABLE SIGNAL 15/15P 1.8M+PEBAG
Accessories:
[Adapter,
Remote
Control]
5F.26J1K.061 REMOTE RC-7092-01-0015 VG30
4J.03A02.011 GUIDE QS VS PJ503D
Documentation:
[Quick Start
Guide, CD Rom]
5B.03A01.011 CD USER MANUAL PJ503D
4B.01214.001 BAG HDPE+LDPE 415*365*0.4
4B.M0628.001 HANDLE HOLDER PE/PP V-05 DE350
4D.01201.041 CTN VIEWSONIC
4G.03A02.001 CUSHION LEFT EPE VG30
4G.03A03.001 CUSHION RIGHT EPE VG30
Packing
Material: [Box,
Foam]
4B.71509.003 BAG LDPE 201*332
