take off the
push button
and the adjust
foot,
disassembly
the screw*6
and clip*3, the
left is lower
case
push button;
adjust foot;
screw*6
clip*3;
lower case
16
disassembly
the
screw*1,take
off the CW
shielding,
disassembly
the screw*1
and take off the
CW module
screw*2;
CW
shielding;
CW module
push
adjust
foot
CW MODULE
