ViewSonic PJD5122 Service Manual

Calculated
60000 hours except DMD chip, Color
wheel, Lamp and Ballast
8.2 Lamp Lifetime
Normal : 3000 hours
Eco: 4000 hours (50% of projector will have 50% initial
minimum brightness)
9.0 Power Requirements Adhere to Appendix 3
9.1 Power Supply (Normal) VAC 100 – 240 (50/60Hz),
Typical 315W Max.
9.2 Power consumption
Standby
10W max. (with loop through)
1W max. @100~240VAC, loop through is
disabled
9.3 Power Connector IEC 60320 C14
10.0 Panel Specification
10.1 Type 0.55” SVGA 2xLVDS 450 Series DMD
10.2 Pixels H: 800 X V: 600
10.3 Color Depth 30 Bits (1.07 Billion Colors)
11.0 Compatibility Appendix 3
11.1 PC
PC Compatible 640X480 ->1024X768, compressed
1600X1200; Composite-Sync; Sync-on-Green
11.2 Video
NTSC/ NTSC4.43/ PAL (Including PAL-M, PAL-N)/ SECAM/
PAL60/
11.3 YpbPr
NTSC (480i)/ 480p/ PAL (576i)/ 576p,
HDTV (720p/1080i/1080p)
11.4 DDC EDID 1.3
12.0 Image Interface Adhere to Appendix 3
12.1 Analog RGB Input
15 pin D-Sub (Female) x 2
G(Y): Video amplitude 0.7/1.0 Vp-p : Impedance 75Ω
RB(CbCr): Video amplitude 0.7 Vp-p : Impedance 75
Ω
HD/VD/CS: TTL Level
12.2 Video Input
RCA jack (Yellow)
Video amplitude 1.0 V
p-p
: Impedance 75Ω
12.3 S-Video Input
4 pin Mini-Din (Female)
Y: Luminance amplitude 1.0 V
p-p
: Impedance 75Ω
C: Chroma amplitude 0.286 V
p-p
: Impedance 75Ω
12.4 YPbPr Input 15 pin D-Sub (Female) x 2
Y: Luminance amplitude 1.0 V
p-p
: Impedance 75Ω
PbPr/C
b
C
r
: Chroma amplitude 0.7 V
p-p
: Impedance 75Ω
12.5 Analog RGB Output 15 pin D-Sub (Female) x 1 (Only Computer 1)
G(Y): Video amplitude 0.7/1.0 Vp-p : Impedance 75Ω
RB(CbCr): Video amplitude 0.7 Vp-p : Impedance 75Ω
HD/VD/CS: TTL Level
13.0 Control Interface
13.1 IR Receiver
IR Receiver x 1 (Front)
Angle: ±30° Distance 0~8m
13.2 Serial Connector RS232 8pin, command table adhere to Appendix 3
14.0 User Interface Adhere to Appendix 3
14.1 Operator Keypad
9 Keys:
Left/ BLANK ; Right/PANEL KEY LOCK ; UP/ KEYSTONE + ;
Confidential - Do Not Copy
PJD5122
ViewSonic Corporation
7

ViewSonic PJD5122 Specifications

General

Projection distance	1.2 - 11.3 m
Vertical scan range	48 - 120 Hz
Horizontal scan range	31 - 100 kHz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	30 - 300 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 40 °
Resolution	1280 x 1024 pixels
Aspect ratio	4:3, 16:9
RS-232 ports	1
Weight (imperial)	5.1 lbs
Dimensions (WxDxH)	264 x 225 x 96.4 mm
Power requirements	100 - 240 V, 50/60 Hz
Connectivity technology	Wired
Lamp power	220 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	6000 h
Focus	Manual
Focal length range	- mm
Full HD	No
HD-Ready	Yes
Analog signal format system	SECAM
RMS rated power	5 W
Audio (L/R) in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	2
Cables included	VGA
Noise level	32 dB
Certification	CB, RoHS, WEEE, UL/cUL, FCC-B, ICES-003, IRAM, NOM, PSB, C-tick, EK, CE, TUV/GS, GOST-R, SASO UKrSEPRO, CCC
Noise level (economic mode)	26 dB
Power consumption (standby)	1 W
Power consumption (typical)	280 W
Operating altitude	1.8 - 3048 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Market positioning	Presentation

Weight and Dimensions

Weight	2300 g
