ViewSonic PJD5122 User Manual

Introduction 9
9. LAMP indicator light
Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem. See "Indicators" on page 49 for
details.
10. AUTO
Automatically determines the best picture
timings for the displayed image. See
"Auto-adjusting the image" on page 25 for
details.
11. Right
Activates panel key lock. See "Locking
control keys" on page 33 for details.
When the On-Screen Display (OSD)
menu is activated, the #6, #7, and #11
keys are used as directional arrows to
select the desired menu items and to make
adjustments. See "Using the menus" on
page 21 for details.
12. MODE/ENTER
Selects an available picture setup mode.
See "Selecting a picture mode" on page 29
for details.
Enacts the selected On-Screen Display
(OSD) menu item.
13. SOURCE
Displays the source selection bar. See
"Switching input signal" on page 24 for
details.
14. Freeze
Freezes the projected image. See
"Freezing the image" on page 34 for
details.
15. / / /
Selects the desired menu items and makes
adjustments. See "Using the menus" on
page 21 for details.
16. MENU
Turns on the On-Screen Display (OSD)
menu.
17. Enter
Enacts the selected On-Screen Display
(OSD) menu item.
18. Keystone keys ( / )
Manually corrects distorted images
resulting from an angled projection.
19. Magnify keys (+, -)
Magnifies or reduces the projected
picture size. See "Magnifying and
searching for details" on page 27 for
details.
20. Blank
Hides the screen picture. See "Hiding the
image" on page 33 for details.
21. Source selection keys (VGA 1/VGA 2/
Video)
Selects an input source for display.
22. Exit
Goes back to previous OSD menu, exits
and saves menu settings.
23.
Toggles the projector audio between on
and off.
24. Color Mode
Selects an available picture setup mode.
See "Selecting a picture mode" on page
29 for details.
25. Volume keys (+, -)
Magnifies or reduces the volume level.

ViewSonic PJD5122 Specifications

General

Projection distance	1.2 - 11.3 m
Vertical scan range	48 - 120 Hz
Horizontal scan range	31 - 100 kHz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	30 - 300 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 40 °
Resolution	1280 x 1024 pixels
Aspect ratio	4:3, 16:9
RS-232 ports	1
Weight (imperial)	5.1 lbs
Dimensions (WxDxH)	264 x 225 x 96.4 mm
Power requirements	100 - 240 V, 50/60 Hz
Connectivity technology	Wired
Lamp power	220 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	6000 h
Focus	Manual
Focal length range	- mm
Full HD	No
HD-Ready	Yes
Analog signal format system	SECAM
RMS rated power	5 W
Audio (L/R) in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	2
Cables included	VGA
Noise level	32 dB
Certification	CB, RoHS, WEEE, UL/cUL, FCC-B, ICES-003, IRAM, NOM, PSB, C-tick, EK, CE, TUV/GS, GOST-R, SASO UKrSEPRO, CCC
Noise level (economic mode)	26 dB
Power consumption (standby)	1 W
Power consumption (typical)	280 W
Operating altitude	1.8 - 3048 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Market positioning	Presentation

Weight and Dimensions

Weight	2300 g
