9
Using the LCD Display
Setting the Timing Mode
Setting the timing mode is important for maximizing the quality of the screen image
and minimizing eye strain. The timing mode consists of the resolution (example
1024 x 768) and refresh rate (or vertical frequency; example 60 Hz). After setting
the timing mode, use the OSD (On-screen Display) controls to adjust the screen
image.
For optimal picture quality, please use the recommended timing mode specific to
your LCD display listed on the “Specification” page.
To set the Timing Mode:
Setting the resolution: Access "Appearance and Personalization" from Control
Panel via the Start Menu, and set the resolution.
Setting the refresh rate: See your graphic card’s user guide for instructions.
IMPORTANT: Please make sure that your graphics card is set to 60Hz vertical
refresh rate as the recommended setting for most LCD displays. Choosing a non-
supported timing mode setting may result in no image being displayed, and a
message showing “Out of Range” will appear on screen.
OSD and Power Lock Settings
OSD Lock: Press and hold [1] and the up arrow ▲ for 10 seconds. If any buttons
are pressed the message OSD Locked will display for 3 seconds.
OSD Unlock: Press and hold [1] and the up arrow ▲ again for 10 seconds.
Power Button Lock: Press and hold [1] and the down arrow ▼ for 10 seconds.
If the power button is pressed the message Power Button Locked will display
for 3 seconds. With or without this setting, after a power failure, your LCD
display’s power will automatically turn ON when power is restored.
Power Button Unlock: Press and hold [1] and the down arrow ▼ again for 10
seconds.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ViewSonic TD1711 and is the answer not in the manual?

ViewSonic TD1711 Specifications

General IconGeneral
Colorblack
Screen Typeled
Tiltableyes
Wall Mount100mm x 100mm
Touch Screenyes
Webcamno
OS Compatibilitywindows
Screen Size17 inches
Panel Typetn
Aspect Ratio5:4
Resolution1280 x 1024
Native Resolution1280 x 1024
Refresh Rate60hz
Horizontal Viewing Angle170 degrees
Vertical Viewing Angle160 degrees
Response Time5 milliseconds
Brightness250 candela per square meter
Contrast Ratio20, 000, 000:1
Synchronizationnot applicable
Horizontal Scan Rate82 kilohertz
HDRno
Built-In Speakersyes
Interface Connectors1 x vga
HDMI Ports1
USB Ports2 x usb-a 2.0
DVI0
Headphones Outputno
Voice Assistantno
Power Saving Mode0.3 watts
Power Consumption12.6 watts
Depth with Stand14.5 inches
Height with Stand13.7 inches
Width with Stand14.5 inches
Depth without Stand8.2 inches
Height without Stand12.4 inches
Net Weight without Stand8.6 pounds
